Eventuri Black Carbon Stage 3 Intake System Audi 8V Gen 2 RS3 / 8S TTRS
With the 8V RS3 Gen 2 and TTRS 8S platforms being widely used for high power builds, we have developed a groundbreaking intake system to support even those exceeding the 1000whp mark. This stage 3 intake system has been developed to offer the highest possible flow rate whilst maintaining the lowest intake temperatures possible. Each component has been designed to provide the turbo with a smooth and free flowing path. The intake tube has an internal diameter of 103mm or just over 4” and has a smooth curvature from the filter housing all the way to the turbo inlet. The filter itself has been specifically designed for this intake and has a huge outer diameter of 210mm or 8.3” with a filtration surface area of over 130,000mm². The patented Venturi housing has been designed to provide the maximum internal volume possible for the RS3 engine bay space available and provides laminar flow to the turbo tube. Finally, the duct seals the filter opening to the front slam panel but is not restricted by just the stock entry feed. We have lifted the front of the duct to now provide an extra opening behind the hood which is equivalent to an extra 7” diameter hole for the intake to draw from. The resulting system has the capability of flowing 840 CFM at 28” H2O while keeping intake temperatures at a minimum with the sealed design.
Eventuri
The Eventuri 8V RS3/8S TTRS STAGE 3 intake system consists of a number of components engineered to perform a specific purpose and fabricated to the highest of standards. We use 100% pre-preg carbon fiber with no fibreglass, which means we can achieve a smooth internal surface to maintain smoother airflow. Here are the details for each component and the design ethos behind them:
Each intake system consists of:
- Carbon Fiber Patented Venturi Filter Housing with 103mm Outlet
- Bespoke High Flow Dry Cone Filter
- Carbon Fiber Inlet Duct (compatible with OE and APR throttle body)
- Carbon Fiber Tube with 103mm ID
- OPF (DWNA) Breather adapter
- Heat Shield with Gold Reflective Backing
- Laser Cut Stainless Steel Brackets
- Silicon Breather Hose
- Silicon Couplers and Reducer
- Optional: Carbon Turbo Inlet (EVE-TRB8V8S-LHD-NIL)
Features:
- RS3 Carbon Headlight Duct (EVE-ST38V8S-CF-HDP)
- Performance Gain (RS3 with Stock Turbo): 15-18hp, 19-23ft-lb
- Performance Gain (RS3 with Hybrid Turbo): 25-30hp, 20-24ft-lb
- Flow Bench Data: Stock Intake 530 CFM : Eventuri Intake 840 CFM
Fitment:
- Audi RS3 8V Gen 2
- Audi TTRS 8S including the 2019 OPF DWNA versions.
EVE-ST38V8S-CF-INT
As a large dealer for Eventuri, Vivid Racing keeps a substantial inventory of the EVE-ST38V8S-CF-INT and other Eventuri products in stock, ensuring that enthusiasts can easily access the performance upgrades they need for their Audi RS3 and TTRS vehicles.
Eventuri products are NOT ELIGIBLE FOR RETURNS
Proposition 65
⚠ WARNING:
Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov
Fitment
|
Make Vehicle | Model | Year |
|---|---|---|
|
2015-2020 Audi RS3 | RS3 | 2015-2020 |
|
2015-2021 Audi TT MK3 | TT MK3 | 2015-2021 |
About Brand
How Did Eventuri Start?
When it comes to performance upgrades, it is common for people to think about camshafts, suspensions, pistons turbochargers and superchargers. But equally as important is upgrading your intake system. It is the component responsible for drawing air to engine which is a critical component in its combustion process. Not all intake system are alike and Eventuri is one of the few companies that creates a product that actually works.
Eventuri was founded by a knowledgeable team of engineers and auto enthusiasts who shared a background in aeronautics and tuning, as well as a passion for high-performance cars. Having all these knowledge and expertise under one roof allows the company to create the best performing intake system available in the market.
After owning several intakes and finding them to be disappointing in terms of gains, the team decided to take it upon themselves and make a change. They set out to reinvent the benchmark in the intake market when it comes to design, technology, and engineering. The ultimate goal was to provide real gains to consumers and publish genuine figures that live up to their claims. Today, they are known as one of the most prestigious air intake manufacturers in the automotive industry.
What Makes Eventuri So Special?
With so many aftermarket intakes available in the market, it begs the question, “What is so special about the Eventuri intakes?” Well, there are three elements that help explain what sets Eventuri apart from other brands. The first is the patented Eventuri filter housing design. The second being the brand’s renown bespoke filters. The third is its emphasis on creating a “Complete Solution” and not cutting corners.
Eventuri’s intake systems are extensively developed using cutting-edge designs and undergo rigorous testing and prototyping methods. The company is primarily focused on performance and numbers; therefore, every single design undergoes CFD analysis and is validated during the prototype stage. It’s at this point where intake temperature and volumetric airflow are measured, and dynamometer testing takes place. Eventuri aims to publish all the information and figures to illustrate the depths in manufacturing an effective intake from the concept stage to market.
Eventuri prides itself in using only the best materials for each component of its intake – even down to the choice of fasteners. The company takes extra steps to ensure that the quality of the products are optimal. This makes them set a new standard in the performance industry.
The company pushes itself even further by offering products made out of the most exotic material such as carbon fiber. This material is often seen in race cars and exotic vehicles due to its strength and lightness. It enables the company to cement their position as the industry leader in their market segment.
Eventuri Parts At Vivid Racing
If you are looking to up your car’s performance and experience a real difference when driving, look no further. Vivid Racing has all the Eventuri parts you need to improve your vehicle’s airflow and efficiency. We carry Eventuri cold air intakes, engine covers, intake boxes and manifolds, scoops, flanges, and hoses. Can’t find a part you’re searching for? Contact our sales team today at (480) 906-4066.
