In the realm of high-performance forced-induction engines, the foundation is everything. For the iconic Nissan VR38DETT powering the R35 GT-R, the margin for error is zero. Factory main bearing cap fasteners, while adequate for stock power levels, become a critical liability when pursuing serious horsepower and enduring track abuse. The ARP 8724 Main Stud Kit (also referenced as ARP 202-5802) is not merely an upgrade; it is an essential engineering intervention. This kit systematically replaces the OE torque-to-yield main cap bolts with a meticulously engineered stud and nut system, fundamentally transforming the crankshaft’s support structure. The result is a bulletproof bottom end capable of withstanding the extreme cylinder pressures and harmonics generated by modified turbochargers, aggressive tuning, and sustained high-RPM operation. For any builder targeting reliability beyond 800 wheel horsepower or preparing for competitive motorsport, the installation of the AR8724 kit is a non-negotiable first step in engine preparation.
The Critical Role of Main Studs in VR38DETT Engine Integrity
The main bearing caps are the anchor points for the crankshaft, containing the tremendous rotational and combustion forces within the engine block. The factory employs torque-to-yield (TTY) bolts, which are intentionally stretched to a precise yield point during installation to achieve clamp load. This is a cost-effective solution but one with significant drawbacks for performance applications: TTY bolts cannot be reliably re-used, their clamping force can relax under thermal cycling, and their ultimate tensile strength is a fraction of that offered by a premium stud system. A stud, by design, provides a superior clamping mechanism. It installs smoothly into the block without applying torsional shear stress during final torque-down—a job handled by the nut. This allows for more accurate, consistent, and repeatable clamp load across all five main caps, virtually eliminating cap walk and fretting, which are primary contributors to main bearing failure in stressed engines.
Engineering Superiority: The ARP 8740 Chromoly Advantage
The AR8724 kit’s dominance is rooted in its material science. Each stud is machined from ARP’s proprietary 8740 chromoly steel, a material whose properties are meticulously controlled from melt to finish. This alloy is heat-treated using ARP’s exclusive process to achieve a tensile strength of 200,000 psi, a figure that dwarfs the capability of OEM fasteners. The real-world benefit is fatigue resistance. Under the dynamic, pulsating loads of a high-boost VR38, lesser fasteners can experience cyclic stress that leads to eventual failure. The 8740 chromoly’s molecular structure and heat treatment provide an exceptionally high endurance limit, meaning it can withstand these repeated stress cycles indefinitely, ensuring the clamping force holding your crankshaft in place remains constant from the first dyno pull to the final lap of a endurance race.
Furthermore, every stud features ARP’s signature Unbrako® thread rolling and precision machining. The threads are not cut; they are formed under immense pressure, which aligns the grain structure of the metal along the thread profile. This creates a smoother, stronger thread with superior resistance to stripping and galling. The included 12-point nuts allow for precise angular torque application in confined spaces, a critical feature when working within the tight confines of the R35’s engine bay. The kit is completed with a high-pressure moly lubricant, engineered to minimize friction variance during installation, which is the enemy of accurate clamp load.
Precision Installation Protocol for the ARP 8724 Kit
Proper installation is paramount to realizing the full performance benefit of these studs. The process requires meticulous block preparation. All original fastener threads in the block must be chased with the correct metric tap to remove any debris, sealant, or minor corrosion. Each ARP stud should then be hand-threaded into the clean, dry block holes until it seats fully at the base of the threads—do not use tools for this initial seating. The main bearing caps are then installed with the bearings and crankshaft in place. ARP provides a specific torque sequence and value, typically involving multiple incremental steps (e.g., 40 ft-lbs, 60 ft-lbs, then a final torque angle) to gradually and evenly compress the cap onto the block. This procedure ensures uniform load distribution across the entire bearing saddle, creating a rigid, undistorted housing for the crankshaft. For detailed technical guidance on VR38 bottom-end assembly, consult this authoritative resource on engine bottom-end assembly basics.
Vehicle Fitment & Application Details
The ARP 8724 Main Stud Kit is engineered as a direct, no-modification replacement for the following applications. Correct fitment is crucial for proper oil clearance and block alignment.
- Nissan GT-R (R35) VR38DETT Engine (2009-2024): All model years and variants, including Premium, Track Edition, NISMO, and 50th Anniversary models.
- Note on Engine Codes: This kit is specifically for the VR38DETT engine found in the R35 chassis. It is not compatible with the VQ or RB series engines from earlier Skyline GT-R models.
- Primary Use Case: High-performance street builds, time-attack, drag racing, and endurance racing applications where engine power output exceeds 700-800 wheel horsepower, or where the engine is subjected to repeated high-load scenarios.
Definitive Benefits of Upgrading to ARP Main Studs
- Unmatched Bottom-End Security: 200,000 psi tensile strength creates an immovable foundation for the crankshaft, preventing catastrophic main cap failure under extreme boost and RPM.
- Eliminates Cap Walk & Bearing Fretting: The stud-and-nut system provides vastly more consistent and stable clamp load, securing the main bearing caps laterally and vertically to protect bearing integrity.
- Superior Fatigue Life: ARP 8740 chromoly steel is engineered for infinite fatigue life under high cyclic loads, a critical factor for turbocharged engines experiencing rapid pressure changes.
- Allows for Precision Machining: A studded block is significantly more stable during align-honing or align-boring operations, ensuring perfect main bore alignment and optimal oil clearance.
- Reusability and Serviceability: Unlike OEM TTY bolts, ARP studs can be removed and reinstalled multiple times without any loss of clamping performance, simplifying future engine service or rebuilds.
Technical Specifications
| Specification | Detail |
|---|---|
| ARP Part Number | 8724 |
| Alternate Part Number | 202-5802 |
| Fastener Material | 8740 Chromoly Steel |
| Tensile Strength | 200,000 PSI |
| Thread Treatment | Rolled (Unbrako® Process) |
| Kit Contents | (10) Main Studs, (10) 12-Point Nuts, High-Pressure Moly Lube |
| Installation Torque | Refer to latest ARP instructions (Typically ~80 ft-lbs final + angle torque) |
